1. Kits Information#
1.1. Introduction#
Ring:bit car is a DIY smart car which is based on Pico:ed board and ELECFREAKS Ring:bit. It adopts modular assembly and programming-driven method, which is easy to learn. It will bring a rich experience to your creation. Next, let’s take a look at the details of the Ring:bit car kit.
Ring:bit has extended 3 channels of GPIO, among which 2 channels are used for driving servos and one channel of GPIO is undefined. Just add one of the many extensions available and your Ring:bit Car can do even more things like line and light following, obstacle avoiding, drawing and more!
Please note that the Ring:bit car version 2 has been upgraded. It is diffrent from the Ring:bit car version 1, all the files mentioned here are in Ring:bit V2.
1.2. Parameter#
| Parameter | Details |
|---|---|
| Working Voltage | 3.5V~5V(3×AAA batteries） |
| Bottom Light | 2 × RGB |
| Mode Switch | RAINBOW LED）and OTHERMODULES |
| Connection | P0、P1、P2(GVS） |
| Servo | 360 degrees digital servo |
| Size | 86 x 80 x 82mm |
1.3. Components list#
| Components | Numbers |
| micro:bit | Optional |
| Ring:bit Expansion Board | 1 |
| Ring:bit Car Expansion Board | 1 |
| Ring:bit Car Front Board | 1 |
| Ring:bit Car Back Board | 1 |
| Ring:bit Car Base Board | 1 |
| Ring:bit Car Side Board | 2 |
| Ring:bit Car Wheel | 2 |
| Binding Post | 1 |
| 360° Servo | 2 |
| Castor Wheel | 1 |
| Screw | 5 |
| Tapping Screw | 5 |
| Rivet | 2 |
| Screwdriver | 1 |
